ExactFlat for SolidWorks is the premier tool for patterning making from 3D to 2D. With an incredible learning time of 4 hours for experienced SolidWorks users, ExactFlat is the fastest way to implement 3D to 2D digital pattern making. The standard workflow is shown below:

The following videos provided an introduction to the ExactFlat for SolidWorks feature set and workflow.

The ExactFlat Database

The ExactFlat for SolidWorks workflow has been optimized to reduce time between workflow steps. This is because the outputs from upstream tasks are incrementally added to the ExactFlat database and therefore immediately available to downstream tasks. Piece names and labels, edge allowances and notch types, and marker and nest properties, lay rules and piece lay rules are all instantly available. This reduces hand times between task to zero. No data re-keying, formatting or errors in translation. The videos below explain more about the ExactFlat Database.

How to Go From 3D to 2D with ExactFlat

3D to 2D flattening is at the heart of the ExactFlat digital patterning feature set. Perfected over many years, going from 3D to 2D is accurate and fast. The videos below will show you how.

Working Beyond Basic Pattern Geometry.

Translating pattern geometry, while accurate and fast in ExactFlat, is still requires the pattern makers eye for things like darts and relief cuts or splitting surfaces. check out the videos below to learn how to add this solutions to your workflow

Nesting & Marker Making

With ExactFlat Professional users have the ability to create markers and automated nests in real-time. Not only do you get the benefit of better yield, you can also benefit from dramatically faster nest creation. Learn how to create a high yield nest in less time than you though possible. Check out the videos below.
